1namespace GoogleARCore.Examples.HelloAR
2{
3　using System.Collections.Generic;
4　using GoogleARCore;
5　using GoogleARCore.Examples.Common;
6　using UnityEngine;
7　using UnityEngine.EventSystems;
8#if UNITY_EDITOR
9　// Set up touch input propagation while using Instant Preview in the editor.
10　using Input = InstantPreviewInput;
11#endif
12　/// <summary>
13　/// Controls the HelloAR example.
14　/// </summary>
15　public class HelloARController : MonoBehaviour
16　{
17    /// <summary>
18    /// The first-person camera being used to render the passthrough camera image (i.e. AR
19    /// background).
20    /// </summary>
21    public Camera FirstPersonCamera;
22
23    /// <summary>
24    /// A prefab to place when a raycast from a user touch hits a vertical plane.
25    /// </summary>
26    public GameObject GameObjectVerticalPlanePrefab;
27
28    /// <summary>
29    /// A prefab to place when a raycast from a user touch hits a horizontal plane.
30    /// </summary>
31    public GameObject GameObjectHorizontalPlanePrefab;
32
33    /// <summary>
34    /// A prefab to place when a raycast from a user touch hits a feature point.
35    /// </summary>
36    public GameObject GameObjectPointPrefab;
37
38    /// <summary>
39    /// The rotation in degrees need to apply to prefab when it is placed.
40    /// </summary>
41    private const float k_PrefabRotation = 180.0f;
42
43    /// <summary>
44    /// True if the app is in the process of quitting due to an ARCore connection error,
45    /// otherwise false.
46    /// </summary>
47    private bool m_IsQuitting = false;
48
49    //オブジェクトの座標を入れる箱を作る
50    public Vector3 pos1 = new Vector3(0,0,0);
51    public Vector3 pos2 = new Vector3(0,0,0);
52    //リスト作成
53    List<GameObject> list_toggle_ = new List<GameObject>();
54
55    /// <summary>
56    /// The Unity Awake() method.
57    /// </summary>
58    public void Awake()
59    {
60        // Enable ARCore to target 60fps camera capture frame rate on supported devices.
61        // Note, Application.targetFrameRate is ignored when QualitySettings.vSyncCount != 0.
62        Application.targetFrameRate = 60;
63    }
64    /// <summary>
65    /// The Unity Update() method.
66    /// </summary>
67    public void Update()
68    {
69        _UpdateApplicationLifecycle();
70        // If the player has not touched the screen, we are done with this update.
71        Touch touch;
72        if (Input.touchCount < 1 || (touch = Input.GetTouch(0)).phase != TouchPhase.Began)
73        {
74            return;
75        }
76        // Should not handle input if the player is pointing on UI.
77        if (EventSystem.current.IsPointerOverGameObject(touch.fingerId))
78        {
79            return;
80        }
81        // Raycast against the location the player touched to search for planes.
82        TrackableHit hit;
83        TrackableHitFlags raycastFilter = TrackableHitFlags.PlaneWithinPolygon |
84            TrackableHitFlags.FeaturePointWithSurfaceNormal;
85        if (Frame.Raycast(touch.position.x, touch.position.y, raycastFilter, out hit))
86        {
87            // Use hit pose and camera pose to check if hittest is from the
88            // back of the plane, if it is, no need to create the anchor.
89            if ((hit.Trackable is DetectedPlane) &&
90                Vector3.Dot(FirstPersonCamera.transform.position - hit.Pose.position,
91                    hit.Pose.rotation * Vector3.up) < 0)
92            {
93                Debug.Log("Hit at back of the current DetectedPlane");
94            }
95            else
96            {
97                    // Choose the prefab based on the Trackable that got hit.
98                    GameObject prefab;
99                    if (hit.Trackable is FeaturePoint)
100                    {
101                        prefab = GameObjectPointPrefab;
102                    }
103                    else if (hit.Trackable is DetectedPlane)
104                    {
105                        DetectedPlane detectedPlane = hit.Trackable as DetectedPlane;
106                        if (detectedPlane.PlaneType == DetectedPlaneType.Vertical)
107                        {
108                            prefab = GameObjectVerticalPlanePrefab;
109                        }
110                        else
111                        {
112                            prefab = GameObjectHorizontalPlanePrefab;
113                        }
114                    }
115                    else
116                    {
117                        prefab = GameObjectHorizontalPlanePrefab;
118                    }
119                    // Instantiate prefab at the hit pose.
120                    var gameObject = Instantiate(prefab, hit.Pose.position, hit.Pose.rotation);
121                    //listにオブジェクトを追加
122                    list_toggle_.Add(gameObject);
123                    // Compensate for the hitPose rotation facing away from the raycast (i.e.
124                    // camera).
125                    gameObject.transform.Rotate(0, k_PrefabRotation, 0, Space.Self);
126                    // Create an anchor to allow ARCore to track the hitpoint as understanding of
127                    // the physical world evolves.
128                    var anchor = hit.Trackable.CreateAnchor(hit.Pose);
129                    // Make game object a child of the anchor.
130                    gameObject.transform.parent = anchor.transform;
131
132            }
133        }
134        //オブジェクトの座標
135        pos1 = list_toggle_[0].transform.position;
136        pos2 = list_toggle_[1].transform.position;
137    }
138    /// <summary>
139    /// Check and update the application lifecycle.
140    /// </summary>
141    /// private voidからpublic voidに変更
142    public void _UpdateApplicationLifecycle()
143    {
144        // Exit the app when the 'back' button is pressed.
145        if (Input.GetKey(KeyCode.Escape))
146        {
147            Application.Quit();
148        }
149        // Only allow the screen to sleep when not tracking.
150        if (Session.Status != SessionStatus.Tracking)
151        {
152            Screen.sleepTimeout = SleepTimeout.SystemSetting;
153        }
154        else
155        {
156            Screen.sleepTimeout = SleepTimeout.NeverSleep;
157        }
158        if (m_IsQuitting)
159        {
160            return;
161        }
162        // Quit if ARCore was unable to connect and give Unity some time for the toast to
163        // appear.
164        if (Session.Status == SessionStatus.ErrorPermissionNotGranted)
165        {
166            _ShowAndroidToastMessage("Camera permission is needed to run this application.");
167            m_IsQuitting = true;
168            Invoke("_DoQuit", 0.5f);
169        }
170        else if (Session.Status.IsError())
171        {
172            _ShowAndroidToastMessage(
173                "ARCore encountered a problem connecting.  Please start the app again.");
174            m_IsQuitting = true;
175            Invoke("_DoQuit", 0.5f);
176        }
177    }
178    /// <summary>
179    /// Actually quit the application.
180    /// </summary>
181    private void _DoQuit()
182    {
183        Application.Quit();
184    }
185    /// <summary>
186    /// Show an Android toast message.
187    /// </summary>
188    /// <param name="message">Message string to show in the toast.</param>
189    private void _ShowAndroidToastMessage(string message)
190    {
191        AndroidJavaClass unityPlayer = new AndroidJavaClass("com.unity3d.player.UnityPlayer");
192        AndroidJavaObject unityActivity =
193            unityPlayer.GetStatic<AndroidJavaObject>("currentActivity");
194        if (unityActivity != null)
195        {
196            AndroidJavaClass toastClass = new AndroidJavaClass("android.widget.Toast");
197            unityActivity.Call("runOnUiThread", new AndroidJavaRunnable(() =>
198            {
199                AndroidJavaObject toastObject =
200                    toastClass.CallStatic<AndroidJavaObject>(
201                        "makeText", unityActivity, message, 0);
202                toastObject.Call("show");
203            }));
204        }
205    }
206　}
207}

1using System.Collections;
2using System.Collections.Generic;
3using UnityEngine;
4using UnityEngine.UI; //UI使用する
5using GoogleARCore.Examples.HelloAR; //名前空間を取得する
6
7 public class UITest : MonoBehaviour
8 {
9 GameObject AR; //HelloARcontrollerを入れる変数
10 GameObject distance; //UIを入れる
11
12 HelloARController script;　//HelloARControllerが入る変数
13 // Start is called before the first frame update
14 void Start()
15 {
16    this.distance = GameObject.Find("Distance");
17    this.AR = GameObject.Find("HelloAR Controller");
18    script = AR.GetComponent<HelloARController>();
19    //GameObjectのHelloAR Controllerの中にあるHelloARController.csを取得して変数に格納
20
21 }
22 // Update is called once per frame
23 void Update()
24 {
25    //HelloARController.csから座標を取得
26    Vector3 p1 = script.pos1;
27    Vector3 p2 = script.pos2;
28
29    //長さを計算
30    float length = (p1 - p2).magnitude;
31    //UIのdistanceを変更
32    this.distance.GetComponent<Text>().text = (length * 100f).ToString("F2") + "cm";
33 }
34}
